Ford
2024 E-Series Cutaway
E-450 DRW 158" WBSTK : R3510N
VIN : 1FDXE4FN3RDD23521
$83,999plus taxes
$547.17
/ bi-weekly plus taxesPowered by
This has no impact on your credit score
Available at Dams Ford Lincoln
Overview
Kilometers
6 km
Engine
7.3 L V8
Transmission
Automatic
Drivetrain
RWD
Passengers
1
Exterior Colour
White
Warranty included
Highlights
Backup camera
Vehicle details
#D5552
CALL our Fleet Account Managers today 604-534-4464 for more information!
Payment OptionsWhich is right for me?
Calculate your payment
Your payment
$547.17
/ bi-weekly plus taxesat our best rate 7.99% APR
| Vehicle Price | $83,999 |
Powered by
This has no impact on your credit score
Features & Specs
- A/C
- Cruise Control
- Keyless Entry
- Power Door Locks
- Adjustable Steering Wheel
- Power Windows
- Intermittent Wipers
- Variable Speed Intermittent Wipers
- Immobilizer
- Trip Computer
- Back-Up Camera
- Auxiliary Audio Input
- WiFi Hotspot
- Adaptive Cruise Control
- Driver Air Bag
- Traction Control
- Automatic Headlights
- Lane Departure Warning
- Front Collision Mitigation
- Automatic Highbeams
- Driver Monitoring
- Bucket Seats
- Rear Wheel Drive
- Dual Rear Wheels
- 8 Cylinder Engine
- Gasoline Fuel
- 6-Speed A/T
- A/T
- ABS
- 4-Wheel Disc Brakes
- Power Steering
- Tire Pressure Monitor
- Steel Wheels
- Running Boards/Side Steps
- Tires - Front All-Season
- Tires - Rear All-Season
- Conventional Spare Tire
Summary
- Vehicle Name
- Ford E-Series Cutaway
- Body Style
- SD Chassis
- Body Code
- H
Transmission
- Drivetrain
- Rear Wheel Drive
- Trans Order Code
- 44P
- Trans Type
- 6
- Trans Description Cont.
- Automatic w/OD
- First Gear Ratio (:1)
- 3.97
- Second Gear Ratio (:1)
- 2.32
- Third Gear Ratio (:1)
- 1.52
- Fourth Gear Ratio (:1)
- 1.15
- Fifth Gear Ratio (:1)
- 0.86
- Sixth Gear Ratio (:1)
- 0.67
- Reverse Ratio (:1)
- 3.13
- Trans PTO Access
- No
- Transfer Case Model
- None
- Transfer Case Power Take Off
- No
Interior Dimensions
- Passenger Capacity
- 2
- Front Head Room
- 42 in
- Front Leg Room
- 42.1 in
- Front Shoulder Room
- 68.1 in
- Front Hip Room
- 65.6 in
Weight Information
- Base Curb Weight
- 5513 lbs
- Gross Axle Wt Rating - Front
- 4600 lbs
- Gross Axle Wt Rating - Rear
- 9600 lbs
- Curb Weight - Front
- 3078 lbs
- Curb Weight - Rear
- 2434 lbs
- Gross Vehicle Weight Rating Cap
- 14000 lbs
- Gross Combined Wt Rating
- 22000 lbs
Trailering
- Dead Weight Hitch - Max Trailer Wt.
- 5000 lbs
- Dead Weight Hitch - Max Tongue Wt.
- 500 lbs
- Wt Distributing Hitch - Max Trailer Wt.
- 7800 lbs
- Wt Distributing Hitch - Max Tongue Wt.
- 780 lbs
- Maximum Trailering Capacity
- 7800 lbs
Engine
- Engine Order Code
- 99N
- Engine Type
- Regular Unleaded V-8
- Displacement
- 7.3 L/445
- Fuel System
- Sequential MPI
- SAE Net Horsepower @ RPM
- 325 @ 3750
- SAE Net Torque @ RPM
- 450 @ 3750
- Engine Oil Cooler
- None
Electrical
- Cold Cranking Amps @ 0° F (Primary)
- 750
- Cold Cranking Amps @ 0° F (2nd)
- 750
- Maximum Alternator Capacity (amps)
- 240 & 157
Suspension
- Suspension Type - Front
- Other
- Suspension Type - Rear
- Leaf
- Spring Capacity - Front
- 4600 lbs
- Spring Capacity - Rear
- 9600 lbs
- Axle Type - Front
- Independent
- Axle Type - Rear
- Rigid Axle
- Axle Capacity - Front
- 5000 lbs
- Axle Capacity - Rear
- 9600 lbs
- Axle Ratio (:1) - Front
- 4.56
- Axle Ratio (:1) - Rear
- 4.56
Tires
- Front Tire Order Code
- T68
- Rear Tire Order Code
- T68
- Spare Tire Order Code
- 51A
- Front Tire Size
- LT225/75SR16
- Rear Tire Size
- LT225/75SR16
- Spare Tire Size
- Full-Size
- Front Tire Capacity
- 5000 lbs
- Rear Tire Capacity
- 9880 lbs
- Revolutions/Mile @ 45 mph - Front
- 709 Rev/Mile
- Revolutions/Mile @ 45 mph - Rear
- 709 Rev/Mile
Wheels
- Front Wheel Size
- 16 X 6 in
- Rear Wheel Size
- 16 X 6 in
- Spare Wheel Size
- Full-Size in
- Front Wheel Material
- Steel
- Rear Wheel Material
- Steel
- Spare Wheel Material
- Steel
Steering
- Steering Type
- Re-Circulating Ball
- Turning Diameter - Curb to Curb
- 54.8 ft
Brakes
- Brake Type
- 4-Wheel Disc
- Brake ABS System
- 4-Wheel
- Brake ABS System (Second Line)
- 4-Wheel
- Disc - Front (Yes or )
- Yes
- Disc - Rear (Yes or )
- Yes
- Front Brake Rotor Diam x Thickness
- 13.6 in
- Rear Brake Rotor Diam x Thickness
- 13.6 in
Fuel Tank
- Fuel Tank Capacity, Approx
- 151.4 L
Exterior Dimensions
- Wheelbase
- 158 in
- Length, Overall
- 261.1 in
- Width, Max w/o mirrors
- 79.4 in
- Height, Overall
- 80 in
- Overhang, Rear w/o bumper
- 68.5 in
- Cab to Axle
- 100 in
- Cab to End of Frame
- 168.5 in
- Ground to Top of Load Floor
- 26 in
Vehicle
- Model Group
- Econoline
- Vehicle Segment
- Chassis
- Vehicle Type
- Chassis
- Body Cab Style
- Chassis
- Engine Displacement Units
- 7.3
- Engine Camshaft
- OHV
- Engine Block Type
- iron
- Engine Cylinder Count
- 8
- Engine Valve Count
- 2
